For Industrial Use, Horizontal Laminar Flow
Features of Clean Bench (AHS161H)
| Model | AHS161H |
|---|---|
| HEPA Filter (mm) | 760 x 915 x 65/2pc 0.3μm DOP scan test 99.99 % or more |
| Weight | 260kg |
| Air flow direction | Horizontal |
| Cleanliness | Class 100 |
| Blow-off air speed (m/sec) | Apprx. 0.40 at early stage, Apprx. 0.20 final |
| Illuminance (lx) | 1000 (in the center of working face) |
| Load bearing of working face | 50kg (static load) |
| Air volume | Approx.33 m3/min |
| Exterior Material | Cold roll steel sheet (chemical-resistant coating), white |
| Interior Material | Stainless steel (SUS304) |
| Working surface | Stainless steel (SUS304), wire drawing processing |
| Item Code | A000632 |
| Socket | AC220V or AC115V 5A 2 outlets with grounding wire 2 (total capacity is 5A) |
| Front filter (mm) | 400 x 400 x 15 / 2pc. |
| Flourescent lamp | 40W x 4pcs. |
| Blower (single phase) | 120W x 2 |
| Working surface level adjustment | Using adjusting foot (-18~+40mm) |
| Display of pressure difference | Differential pressure gauge |
| Accessories | Fixing fittings of adjusting foot x 4 |
| Optional item | Air velocity controller: displays blow-off air speed and with variable air speed device |
| Internal dimensions（H mm） | 875mm |
| External dimensions（W×D×H mm） | 1600×770×1725mm |
| Power Source | AC220V 15A |
