Description
Basic fixed setting forced air convection ovens
Features of Economical Forced Convection Oven (DKM600)
Economical Forced Convection Oven (DKM600)
Economical Forced Convection Oven (DKM600)
Additional information
| Model | DKM600 |
|---|---|
| Temp. controller | PlD control by microprocessor |
| Internal dimensions（W×D×H mm） | 600×500×500mm |
| Shelf support | 4 pcs. |
| Shelf plate quantity | 2 pcs. |
| Shelf plate | Stainless steel |
| Shelf support pitch | 30mm |
| Temp. setting method | Operation menu key and digital setting by UP/DOWN key |
| Safety device | Self diagnostic functions (Sensor trouble detection, Memory error, Measured temperature lower limit error, Measured temperature error), Auto overheat prevention, Independent overheat prevention. |
| Shelf plate with standard load | 15kg/pc. |
| Heater circuit control | SSR control |
| Additional functions | Calibration off-set function, Key lock, Uninterruptible power for memory |
| Operation functions | Fixed temperature operation, Quick Auto-stop, Auto start, Auto stop |
| Timer | 1 min. to 99 Hrs. 59 min. and 100 Hrs. to 999 Hrs. 50 min. (with time wait function) |
| Weight | 65kg |
| External dimensions（W×D×H mm） | 710×651×870mm |
| Internal capacity | 150L |
| Shelf support step number | 13 steps |
| Exhaust port | 30 mm l.D.×2 pcs.(the top) |
| Operating Temperature Range | Room temp. +10~260°C |
| Heater Power | 1.34kW |
| Heat insulating material | Glass wool |
| Exterior material | Cold rolled steel plate with melamine resin baking finish |
| Interior material | Stainless Steel |
| Max. temp. reaching time | Approx. 90 min. (at room temp. +10°C~260°C) |
| Temp display method | Measurement temp. : Digital display by green LED Setting temp. : Digital display by red LED |
| Temp. control accuracy | ±1°C (at 210°C) |
| Temp. distribution accuracy | ±2.5℃（at 210℃） |
| Circulation Method | Forced air circulation |
| Item Code | 212878 |
| Power Source | AC220V 7A |
| Heater | SUS pipe heater |
| Sensor | K-thermocouple |
| Cable port | 30 mm l.D.×1 pc. (right side) |
| Fan type / Motor | Scirocco fan / Condenser type motor |
