Easy to use, digital setting, compact design oil bath
Features of Economical Oil Bath (BO410)
| Model | BO410 |
|---|---|
| Item Code | 222115 |
| Weight | 5.5kg |
| Operating temp. range | Room temp. +10 to 180°C |
| Temp. control accuracy | ±2°C (at agitation) |
| Temp. control system | PlD control by microprocessor |
| Temp. setting / display method | Digital setting by ▲/▼ keys |
| Operation function | Keypad lock, RE signal transmission and reception, Power failure recovery, Calibration off-set |
| Heater | 1kW（200V） 1.44kW (240V) |
| Sensor | K thermocouple |
| Safety device | Bath protection cover (ABS heat-resistant resin) |
| Safety device 2 | Self-diagnostic function (Automatic overheat prevention, Temperature sensor error, Triac short circuit, Heater disconnection, Main relay failure), Circuit protector, Thermal fuse, Micro switch to detect heating without oil |
| Interlocking control function | RE601/801 signal transmission and reception (Constant operation, Heat retention operation, Stop), Error report to RE601/801 |
| Internal dimensions（φ×H mm） | φ240×122mm |
| External dimensions（W×D×H mm） | 340×349×231mm |
| Remarks(dimensions) | Tank maximum inner diameter 240× bottom diameter φ165×D122mm approx.4L |
| Power Source | AC200 to 240V 5.5 to 6.5A |
