Description
Features of Fume Hood (Double faced type) (LDD-N150L)
Fume Hood (Double faced type) (LDD-N150L)
Fume Hood (Double faced type) (LDD-N150L)
Additional information
| Model | LDD-N150L |
|---|---|
| Safety feature | Exhaust delay timer, Door falling prevention stopper, Flow monitor |
| Static pressure | 109 Pa |
| Standard discharge air quantity | 24 m3/min |
| Weight | 360kg |
| Power Source | AC115/220V |
| External dimensions（W×D×H mm） | 1500×1200×2400mm |
| Option | Gas tap, LED, Safety mechanism |
| Fluorescent lamp | 32W 2sets |
| Item Code | A003020 |
| Outlet | AC115/ 220V with dual grounding wire (dropout prevention) 2pcs |
| Water faucet | Single type 2pcs |
| Glass window | Tempered glass 6mm Balance weight |
| Working surface materials | Stainless steel (L) |
| Interior | Non-asbestos and non-combustible decorative board (Baffle plate: multi slit system) |
| Exterior | Cold-rolled steel plate (chemical resistance baking finish) |
