Description
Features of Fume Hood (for Medium Level RI) (LDM-N150L)
Fume Hood (for Medium Level RI) (LDM-N150L)
Fume Hood (for Medium Level RI) (LDM-N150L)
Additional information
| Model | LDM-N150L |
|---|---|
| Water faucet | Single type 2pcs |
| Static pressure | 147 Pa |
| Standard discharge air quantity | 28 m3/min |
| Option | Gas tap, LED, Safety mechanism |
| Safety feature | Door falling prevention stopper, Flow monitor |
| Fluorescent lamp | 32W 1set |
| Outlet | AC115/ 220V with dual grounding wire (dropout prevention) 1pc. |
| Glass window | Tempered glass 6mm Balance weight |
| Item Code | A003029 |
| Working surface materials | Stainless steel (L) SUS304 1.5mm thickness (Max. load : 1000 kg) |
| Interior | Stainless steel SUS304 1.5mm thickness (Baffle plate: multi slit system) |
| Exterior | Cold-rolled steel plate (chemical resistance baking finish) |
| Weight | 430kg |
| Power Source | AC115/220V |
| External dimensions（W×D×H mm） | 1500×900×2400mm |
