Features of Fume Hood (Perchloric Acid-resistant) (LDP-N120S)
Fume Hood (Perchloric Acid-resistant) (LDP-N120S)
Fume Hood (Perchloric Acid-resistant) (LDP-N120S)
Additional information
| Model | LDP-N120S |
|---|---|
| Item Code | A003031 |
| Static pressure | 108 Pa |
| External dimensions（W×D×H mm） | 1200×900×2400mm |
| Power Source | AC115/220V |
| Weight | 240kg |
| Exterior | Cold-rolled steel plate (chemical resistance baking finish) |
| Interior | Heat resistant vinyl chloride resin (Baffle plate: multi slit system) |
| Working surface materials | Ceramitite (S) |
| Glass window | Tempered glass 6mm Balance weight |
| Water faucet | Single type 1pc |
| Outlet | Socket AC115/220V × 2pcs |
| Fluorescent lamp | 32W 2sets |
| Safety feature | Exhaust delay timer, Door falling prevention stopper, Flow monitor |
| Pushed air method | Vinyl chloride resin |
| Option | Gas tap, LED, Safety mechanism |
| Standard discharge air quantity | 24 m3/min |
