Description
Features of Fume Hood (Wet Scrubber Built-in Type) (LDC-N120S)
Fume Hood (Wet Scrubber Built-in Type) (LDC-N120S)
Fume Hood (Wet Scrubber Built-in Type) (LDC-N120S)
Additional information
| Model | LDC-N120S |
|---|---|
| Item Code | A003042 |
| Operating Weight | 370 kg |
| Exterior | Cold-rolled steel plate (chemical resistance baking finish) |
| Interior | Non-asbestos and non-combustible decorative board (Baffle plate: multi slit system) |
| Working surface materials | Ceramitite (S) |
| Glass window | Tempered glass 6mm Balance weight |
| Water faucet | Single type 1pc |
| Outlet | AC115/ 220V with dual grounding wire (dropout prevention) 1pc. |
| Fluorescent lamp | 32W 1set |
| Washing method | Multistage packed tower system (chemical washing) |
| Circulation Pump | 180/216W (50/60Hz) AC200V 3-phase |
| Safety feature | Exhaust delay timer, Door falling prevention stopper, Flow monitor, Washing tower water level abnormality sensor |
| Option | Gas tap, LED, Safety mechanism, Water leakage detector, Opening limit stopper |
| Standard discharge air quantity | 12 m3/min |
| Static pressure | 170 Pa |
| External dimensions（W×D×H mm） | 1200×850×2600mm |
| Power Source | AC115/220V |
| Weight | 273kg |
