Safe, Easy-operation, Space-saving Fume Hoods
Features of My Hood (Compact Fume Hood) (MS-90)
| Model | MS-90 |
|---|---|
| Safety structure | Brake block to prevent door from falling down / Door opening extent sticker |
| Weight | 130kg |
| Exhaust damper | Stainless steel, inner diameter ø150, outer diameter ø152, Fixed by flange |
| Matched Pipe | Hard polyethylene, inner diameter ø160, outer diameter ø165 |
| Flourescent light | Single phase AC 220V 20W single light |
| Water exhaust pipe | Hard polyethylene / Single tube fixed (outer diameter ø40, Inner diameter ø31) |
| Exterior | Cold-rolled steel plate, chemical proofing powder coating, with adjusting casters |
| Interior | Hard polyethylene |
| Working face | Hard polyethylene |
| Glass door | Toughened glass 5mm. Close and open (up and down) with balance block |
| Item Code | A001060 |
| Internal static pressure Pa (mm H2O) | 40 (4) |
| Air volume | 7m3/min |
| Worktop | Stainless steel (SUS304) |
| Worktop load bearing | Uniformly-distributed load 50kg |
| Temperature and humidity condition of location | 5~35°C, 20~80% (no frosting) |
| Tap | Gooseneck tap, nominal value 1/2B flexible tube, external or internal thread fixing |
| Device of waste liquid | Unit body (tray): cold-rolled steel plate (chemical proofing powder coating), with casters, 20L polyurethane bottle, connecting tools of draining water (nut, hose, steel wire hoop) |
| Accessories | Fixing bolts for upper and lower bodies fixing, fixing fittings of wall and ground, tools for adjusting foot, cover of water outlet, shock pads, front operation panel |
| External dimensions（W×D×H mm） | 900×750×1850mm |
| Power Source | AC115 / 220V |
