Description
Standard equipped with Overheat Prevention Device, Electric Leakage Breaker
Features of Water Bath (Constant Temp.) (BS200)
- BS200
- With 4 kinds of Baskets. Max. 5L Beaker can be set by removing Lid.
Water Bath (Constant Temp.) (BS200)
Water Bath (Constant Temp.) (BS200)
Additional information
| Model | BS200 |
|---|---|
| Opening Size, Q’ty | ― |
| Weight | 5kg |
| Power Source | AC115/220V |
| Remarks(dimensions) | Effective Inner Dimension φ186× Depth 115mm ・Internal capacity 4.7L |
| External dimensions（W×D×H mm） | 300×364×216mm |
| Internal dimensions（φ×H mm） | φ200×149mm |
| Accessory | Ring (Not including BS200), Lid, Container Fixing Clamp, Stand, Bar for Clamp Fixing (Not including BS200), Connector for Stand, Thermometer (-10°C to +110°C Alcohol Type), Bottom Plate, Basket (Only for BS200) |
| Safety Countermeasure | Overheat Prevention System (Liquid Expansion Type, Self SustainingRelay, Alarm Lamp On) Electric Leakage Breaker with Over CurrentProtection (Power Lamp On at the time System On) |
| Item Code | 222061 |
| Heater | Copper Pipe Heater (Nickel Plated) 900W |
| Inner Bath | Stainless Steel |
| Time to Reach to Constant Max. Temp | Approx. 30min |
| Temp. distribution accuracy | ±5°C (at 70°C ) |
| Temp. adjustment accuracy | ±3°C (at 70°C ) |
| Operating temp. range | Room Temp. +5°C to Boiling Temp. (Water) |
