Description
Standard equipped with Overheat Prevention Device, Electric Leakage Breaker
Features of Water Bath (Constant Temp.) (BS660)
- BS660
- Can use 6pcs. of Big/Small Container and can adjust the sink level.
Water Bath (Constant Temp.) (BS660)
Water Bath (Constant Temp.) (BS660)
Additional information
| Model | BS660 |
|---|---|
| Opening Size, Q’ty | φ115mm, 6pcs |
| Weight | 12kg |
| Power Source | AC115V/220V |
| Remarks(dimensions) | Effective Inner Dimension L468×W260×D66mm ・Internal Capacity Approx.14L |
| External dimensions（W×D×H mm） | 565×437×214mm |
| Internal dimensions（φ×H mm） | 502×302×99mm |
| Accessory | Ring (Not including BS200), Lid, Container Fixing Clamp, Stand, Bar for Clamp Fixing (Not including BS200), Connector for Stand, Thermometer (-10°C to +110°C Alcohol Type), Bottom Plate, Basket(Only for BS200) |
| Safety Countermeasure | Overheat Prevention System (Liquid Expansion Type, Self Sustaining Relay, Alarm Lamp On) Electric Leakage Breaker with Over CurrentProtection (Power Lamp On at the time System On) |
| Item Code | 222064 |
| Heater | Copper Pipe Heater (Nickel Plated) 1.3kW |
| Inner Bath | Stainless Steel |
| Time to Reach to Constant Max. Temp | ±5°C (at 70°C ) |
| Temp. distribution accuracy | ±3°C (at 70°C ) |
| Temp. adjustment accuracy | Room Temp. +5°C to Boiling Temp. (Water) |
| Operating temp. range | Approx. 60min. |
