Water Purifier (RO + Ion-exchange) (WE200)

Description

Type 1 (ASTM D 1193) / A4 (JIS K 0057) level purity benchtop water purifier.

Features of Water Purifier (RO + Ion-exchange) (WE200)

Features: Lower running cost.
Features: By adopting reverse osmosis (RO) membrane cartridge set, life span of consumables has been expanded significantly.
Features: Benchtop type, space saving.
Features: Easy water sampling by attaching to water faucet.
Features: Easy to operate digital display.
Features: Displays replacement of consumables and its exchange history.
Features: Standard equipped with membrane filter to protect pure water production from contamination.
Features: Electromagnetic valve equipped at sampling water port for leakage prevention.
Features: Universal power supply: works with 100 to 240VAC.

Model	WE200
Raw water press range	0.13 to 0.5MPa (1.3 to 5.0kgf/cm²)
Weight	30kg
Purified water	Deionized water: JIS K0057 A4
Water purifying method	RO membrane→Ion exchange→filtration
Pure water delivery rate	0.5 to 1.0L/min continuous production
Raw water filter	Pre-treatment cartridge (activated charcoal + 0.1μm hollow fiber membrane)
Filtration	Reverse osmosis membrane (RO)
Ion-exchange resin cartridge	2L ion exchange resin containing activated charcoal (CPC-T)
Final filtration	0.1μm membrane filter
Leakage detection	Water supply solenoid valve forcibly shut off when leak is detected
Item Code	253682
Water sampling port	250mm above floor, RC1/4 (Connected with membrane filter)
Raw water temperature range	10 to 30°C
Drainage port	ø10 rigid tube
Drainage rate	Maximum 2.2L/min. (in flushing operation)
Safety device	Water cut-off error, Water quality sensor error, Controller error, Pressure limit error, Leak error, Flow alarm/Error, Earth leakage circuit breaker
Water quality display	7-segment LED display (Conductivity / Resistivity / Water temperature)
Other display	Consumables replacement display (Ion exchange resin, Pre-treatment cartridge, Reverse osmosis (RO) membrane, Membrane filter), Warning / Error display
Accessories	Supply water hoses, Pre-treatment cartridge, Reverse osmosis (RO) membrane cartridge set, Ion-exchange cartridge CPC-T, Membrane filter, Drain hose, Power cord, Seal tape
External dimensions（W×D×H mm）	350×430×470mm
Power Source	AC100 to 240V 1.3A Single-phase
